Setup
Licensing & software
This device is an Official Serato Accessory. It requires a Serato DJ Pro-supported primary device to be connected alongside it.
The links below show a complete list of supported primary hardware.
Please ensure you have the latest version of Serato DJ Pro installed:
Drivers & firmware
The Reloop NEON does not require manufacturer-specific drivers on Mac or Windows operating systems and is plug-and-play with Serato DJ Pro. Connect the Reloop NEON to a USB port on your computer, ensuring your primary hardware is connected, and launch Serato DJ Pro.
Overview
| # | NEON CONTROL | FUNCTION |
SHIFT |
| 1 | LEFT DECK/BROWSER KNOB | Turn for Library scroll. Press to load track. | Turn to adjust Sampler volume. Press to toggle Back through areas. |
| 2 | SAMPLER | Press once for SAMPLER mode. Press twice for PAD FX | Enable velocity sensitivity (Pads will illuminate green) |
| 3 | SLICER | Press once for SLICER mode, press twice for LOOPED SLICER | - |
| 4 | PERFORMANCE PADS | SEE PERFORMANCE PADS SECTION FOR MORE INFO | - |
| 5 | HOT CUE | Press once for HOT CUE mode. Press twice for FLIP* mode | - |
| 6 | HOT LOOP | Press once for HOT LOOP mode, press twice for MANUAL LOOP mode | - |
| 7 | RIGHT BROWSER KNOB | Press to enable Auto Loop. Turn to adjust loop length | Turn to shift loop left or right. Press to enable loop roll. |
| 8 | MODE/CENSOR | Censor | Enables REL mode (if hardware available) |
| 9 | SLIP | Enables Slip mode | Enables INT mode |
| 10 | SYNC | Enables SYNC | Turns SYNC off. Press twice to reset to absolute pitch. |
| 11 | SHIFT | Used with other functions with Shift modifier controls | - |
| 12 | BANK/DECK D | Switches to Sampler Bank D | Arms a Flip* for recording |
| 13 | BANK/DECK C | Switches to Sampler Bank C | Turns current Flip* On/Off |
| 14 | BANK/DECK B | Switches to Sampler Bank B | Turns Flip* loop On/Off |
| 15 | BANK/DECK A | Switches to Sampler Bank A | Retriggers current Flip* |
| 16 | USB | Connect the Reloop NEON to your computer with a USB Mini cable | - |
| 17 | LINK | Link multiple Reloop NEONs together to use in series | - |
Performance Pads
The Reloop NEON has 8 performance pads, which can be used in 4 different performance pad modes.
These consist of:
SAMPLER Mode: Pads 1-8 trigger samples loaded in your Sample Banks. Holding MODE and pressing a pad will change the trigger type. Holding SLIP and pressing a pad will toggle Loop on and off for that Sampler slot. Holding SYNC and pressing a pad will enable SYNC for that Sampler slot. Press SAMPLER twice to enable PAD FX mode. Hold SHIFT and press the SAMPLER button to enable velocity sensitivity.
SLICER Mode: A specified range (or domain) is divided into eight equal sections, and these eight sliced sections are assigned to the respective performance pads. Pressing SLICER once for the first mode activates a shifting Slicer Domain. Pressing SLICER twice for the second mode activates a fixed Slicer Domain or LOOPED SLICER. Hold SHIFT and press a pad to set the domain length. The domain can be set to one of six settings: 2 beats, 4 beats, 8 beats, 16 beats, 32 beats, or 64 beats.
HOT CUE Mode: When pressing buttons 1-8, you can add up to 8 Cue Points. Holding SHIFT and pressing buttons 1-8 will delete the Cue Points. Press HOT CUE again to enable saved FLIP mode. Use this mode to save or trigger saved Flips* you have created. Pressing a pad while the current Flip is active will save the Flip to that slot.
HOT LOOP Mode: When pressing pads 1-8, you can activate saved Loops. You can also use the AUTO LOOP knob to set auto loops. See LOOPING for more information. Pressing LOOP twice will enter MANUAL LOOP mode: Pressing buttons 1-8 can set, save, and launch previously made Manual Loops. See LOOPING for more information.
Looping
In Serato DJ Pro, you can have up to 8 Saved Loops per track and choose between manual or auto looping.
Auto Loop Mode
| NEON CONTROL | FUNCTION |
SHIFT |
| PAD 1 - 8 | Save active Loop to slot | Re-trigger Loop |
|
LOOP SET (press knob) |
Auto Loop On/Off | Enable Loop Roll |
|
LOOP SIZE (turn knob) |
Adjust Loop size | Shift Loop Left/Right |
Manual Loop Mode
| DDJ-SP1 CONTROL | FUNCTION |
SHIFT |
| PAD 1 | Turn the current Loop On/Off. | - |
| PAD 2 | - | Jump to and turn on Loop (Reloop) |
| PAD 3 | Save the loop to the selected Saved Loop slot | - |
| PAD 4 | Scrolls up through available Saved Loop slots | - |
| PAD 5 |
Loop In Adjust loop in point (Loop active) |
- |
| PAD 6 |
Loop Out Adjust loop out point (Loop active) |
- |
| PAD 7 | Reloop / Exit Loop | |
| PAD 8 | Scrolls down through available loop slots | |
| LOOP SIZE | Halve/Double Loop length | Shift Loop to the Left/Right |
DJ-FX
The FX panel button is displayed in the top left area of the main Serato DJ Pro screen, click on this to toggle the DJ-FX panel.
With the DJ-FX panel open, you have control of two DJ-FX units, and if your hardware supports it, Channel FX, which can be applied to tracks played through your connected Serato DJ-hardware.
Both DJ-FX & Channel FX can be controlled with your mouse, by using dedicated controls on your hardware (where available), or by MIDI mapping controls to the respective software functions.
Learn more about how to use DJ-FX & Channel FX:
| NEON CONTROL | FX FUNCTION | SHIFT |
| PADS 1-3 | FX Unit 1 Effect On/Off. Velocity Sensitive. | Effect Select FX Unit 1 |
| PAD 4 | Adjust Beats value left | - |
| PAD 5-7 | FX Unit 2 Effect On/Off. Velocity Sensitive. | Effect Select FX Unit 2 |
| PAD 8 | Adjust Beats value right | - |
Flip
Flip is an Expansion Pack for Serato DJ Pro. Flip controls are only available once the Expansion pack has been purchased and activated. The Expansion pack can be bought via Serato.com -https://serato.com/dj/pro/expansions
Please check out our Flip User Guide for more information on using Flip.
In HOT CUE performance pad mode SHIFT + BANK/DECK buttons are used to record, trigger and loop Flips.
| NEON CONTROL | FLIP FUNCTION |
| SHIFT + 1 (REC) | FX Unit 1 Effect On/Off. Velocity Sensitive. |
| SHIFT + 2 (ON) | Starts the current Flip / re-trigger Flip |
| SHIFT + 3 (LOOP) | Turns Flip Loop on/off |
| SHIFT + 4 (START) | Turns current Flip On/Off |
Press Hot Cue mode twice to enter Flip performance pad mode. Pressing pads 1-6 in will trigger saved Flips, pressing SHIFT + pads 1-6 will turn saved Flips on/off. Pressing an empty Flip slot will save any active Flip to that slot.
Help
Show Tooltips
Click on the Help button in the upper right-hand corner of Serato DJ Pro, then Show Tooltips to enable Tooltips. Tooltips provide a handy way to learn the various features of Serato DJ Pro.
Move the mouse over a section of the software to bring up a context-sensitive tooltip that describes the feature.
Click on the Help button again to turn off Tooltips.
Show Shortcut Keys
Click on the Help button in the upper right-hand corner of Serato DJ Pro, then click Show Shortcut Keys to launch a pop-up window displaying shortcut keyboard combinations.
These shortcuts can help you perform various actions quickly, such as triggering specific deck functions, controlling playback, or navigating the library.
Watch Tutorials
Click on the Help button in the upper right-hand corner of Serato DJ Pro, then Watch Tutorials to launch
your default internet browser and watch tutorials to help you get familiar with Serato DJ Pro.
Get Support
Click on the Help button in the upper right-hand corner of Serato DJ Pro, then Get Support to launch your default internet browser and navigate to the Serato DJ Pro knowledge base, where you can find helpful articles and guides on Serato DJ Pro. Alternatively, type keywords in the Search Help box to search the Serato DJ Pro knowledge base for specific, related topics.
